Description
Professional Grade Body Worn Camera
| System | |
|---|---|
| Chip | 8-Core 64-Bit 2.3G CPU |
| System | Android |
| Sensor | OV6489 |
| RAM | 2GB + 32GB ( Optional Up to 256GB ) |
| Screen | 2.4 Inches IPS HD Touchscreen |
| Field of View |
120° |
| Image Resolution |
64 Megapixel |
| Camera Lens |
Scratch Resistant |
| Image Format |
JPEG |
| Front Camera |
12 Megapixel |
| Rear Camera |
5 Megapixel |
| Compression |
H.265 / H.264 |
| Video Format | MP4 H.264 compressed format |
| Video Resolution | 2K, 1920x1080 1280x720, 720x480 |
| One Touch Recording | Yes |
| Pre and Post Recording | Yes |
| Video Input | External USB Camera ( Optional ) |
| Audio | High Quality, Built-in Microphone |
| Compression | Opus |
| Speaker | Built-in |
| Audio PA | Class K |
| Docking Station | Yes, Standby battery and host charge can be charge at the same time |
| Standby Time | 24 hours |
| Continuous Power Supply | Built-in 60 mAh small battery, battery replacement and continuos power |
| Capacity | 11 hours |
| Secondary Light Source | Infrared light, bright white light, laser position |
| Storage Capacity |
Standard 64B storage ( TF cards storage ) |
| Working Temperature | -20 ~ 60 ° C |
| Working Humidity | 40% to 90% |
| Storage Temperature | -40 to 60 ° C |
| Protection Level | IP 68 |
| Military Standard | MIL-STD-810G |
| Dimensions |
91mm x 57mm x 25 mm |
| Weight |
160gh ( without clip ) |
| Communications | |
| GPS | Built-in, GPS/BDS/GLONASS |
| Network |
GSM: B2/3/5/8 WCDMA: B1/2/5/8 TDS: B34/39 FDD_LTE: B1.B2.B3.B4.B5.7.B8.B28A/B TDD_LTE: B38/39/40/41 |
| Wi-Fi | Built-in, 802.11a a/b/g/n 2.4G+5GHz |
| Sim Card Slot | Built-in, Nano-Sim Card |
| G/M-Sensor | Built-in |
| BT | Bluetooth 4.0 LE |
| NFC | Optional |
| SOS Alarm | System should be able to get SOS alarm if personnel are in danger |
| Software | |
| BCMS | Bodycam Management System |
| Face Recognize | Support facial recognition on device side and platform side, which can be developed according to requirement ( optional on 5G model ) |
