Description
Please click the following button for the videos of each AI features
Face
detection
Face
recognition
License plate
detection
License plate
recognition
Pedestrian
& vehicle
Perimeter
intrusion
Line
crossing
Object
detection
Cross
counting
Heat
map
Crowd
density
Queue
length
Rare
sound
Intrusion
Region
entrance
Region
exiting
Video
tampering
Sound
detection
| Camera | |
| Image Sensor | 1/2.8" |
| Scanning System | Progressive Scan CMOS |
| Min.Illumination | Color 0.002Lux @ F1.2 ( AGC ON ); B/W 0 lux @ IR ON |
| WDR | 120 dB |
| Shutter Time | 1/5 ~ 1/20000s |
| Day/Night Mode | Full Color Mode/Day&Night Mode/Smart IIIumination |
| DORI Distance | 2.7 mm: D: 52.8 m, O: 21.1 m, R: 10.6 m, I: 5.3 m / 13.5 mm: D: 259.3 m, O: 103.7 m, R: 51.9 m, I: 25.9 m |
| Digital Noise Reduction | 3D DNR |
| Lens | |
| Focal Length | 2.7 - 13.5 mm |
| Max. Aperture Ratio | F1.2 |
| Angular Field of View | Horizontal: 33~111°, Vertical: 18~57°, Diagonal: 37~134° |
| Min. Object Distance | Approx. 0.2 m (0.98 ft) |
| Lens Type | Motorized Varifocal |
| Zoom | 5x |
| Video | |
| Effective Pixels | 8MP 3840 (H) × 2160 (V)@30fps |
| Resolution | Main Stream: 8MP (3840x2160) 5MP (2592x1944) 4MP (2592x1520) 3MP (2304x1296) 1080P(1920x1080) 720P(1280x720) 960H(1280x960) Sub Stream: 720P(1280x720) VGA (640x480), QVGA (320x240) Mobile Stream: VGA (640x480), QVGA (320x240 |
| Video Compression Format | H.265/H.264/H.265+/H.264+/MJPEG |
| Video BitRate | 256Kbps ~ 16Mbps |
| Bitrate control method | CBR / VBR |
| Audio | |
| Built-in Microphone | N/A |
| Built-in Speaker | N/A |
| Audio Compression | G711A/G711U |
| Custom Voice | YES |
| General | |
| Operating Conditions | -40 ~ +140°F (-40 ~ +60°C)/ less than ≤ 95% RH |
| Protection | IP67 |
| Input Voltage / Current | DC12V/PoE(IEEE802.3af) |
| Power Consumption | DC12V：max 6,9W；POE（48V）：max 8,7W |
| Material | Metal |
| Weight | 2.35lbs (≈ 1 kg) |
| Dimensions | 5.78” x 4.6” (≈ 147 mm × 117 mm) |
| Compatibility | ONVIF( Profile S/G/T/M) |
| On-Board Storage | Micro SD slot, up to 1 TB |
| JUNCTION BOX | WALL MOUNT BRACKET | ACCESSORIES |
|
|
|
|
| Junction Box with Built-in PoE Switch | ||
|
|
