Description
The AI Dashcam is a powerful and fast-installed 1080P AHD recorder for vehicle surveillance. It supports up to 4 channels of video recording, with internal GPS, 4G, and Wi-Fi. The road-facing camera is with built-in ADAS function, and the wide angle 130° in-cabin camera is with DSM function.
It’s suitable for different vehicles, such as taxi, trucks, vans, etc.
- Features
- Hidden antenna design, without external antenna installation.
- Special integrated design to the external GPS module/antenna or in-cabin camera with built-in antenna and provides better GPS signal and performance than other regular dashcam designs, avoid the interference to the GPS signal from the recorder circuit.
- Support up to 4 channels inputs ( 1 x 1080P AHD + 2 x 720P AHD + 1 x 1080P IPC )
- Support ADAS, DSM, face recognition function (optional).
- Dual TF cards video storage, single card supports up to 256GB.
- Compatible with H.265 / H.264 video encoding.
- Built-in Wi-Fi as a hotspot, used for wireless connection between mobile phones and devices, using mobile APP settings to view device parameters, status, playback video, and other functions.
- Support MIC & speaker
- Built-in 1-way yellow and blue bi-color indicator light to indicate the device’s working status, hidden design avoids interfering with the driver’s sight.
- Support an emergency alarm button.
- Support an integrated 3-axis accelerometer (G-Sensor) and 3-axis gyroscopes (total 6 axis), to detect a crash, harsh braking, acceleration, and cornering.
- With a built-in Mini USB 2.0 for export of recorded data and equipment maintenance.
- Support low voltage protection, when the voltage is lower than 8.5V, the device will automatically shut down (shutdown voltage value can be set, the default value is 8.5V).
- 9V-36V DC power supply.
- Operating Temperature -25℃~ + 75℃, Storage temperature -40℃~+80℃.
|
Model |
MVR-DSC-Ai2 |
|
|
AI |
Support ADAS, DSM, |
|
|
Wireless Communication |
Support 4G |
|
|
Support Wi-Fi |
||
|
Storage |
2 TF Card Slots, Support 256G each |
|
|
GPS-mouse |
Support GPS-mouse |
|
|
IO input |
3 Channels，1 channel for the emergency alarm button(Integrated with the power harness) |
|
|
Emergency alarm button |
1 Channel, integrated with the power harness |
|
|
Mini USB 2.0 |
1 Channel（For export of recorded data and equipment maintenance.） |
|
|
G-Sensor |
Accelerometer, Gyroscope 6 axis |
|
|
indicator light |
The indicator light shows four states of the device: After the device is powered on, it is starting: the yellow light is always on. After the device is started, there is no 4G network signal: the yellow light is flashing. The device connection platform is running normally: the blue light is always on. The device has no memory card, or the storage is abnormal: the blue light is flashing. |
|
|
Audio Input |
Built-in 1-channel MIC supports up to 2-channel audio input |
|
|
Audio Output |
Built-in 1-way speaker (8Ω1W) |
|
|
Video input |
Supports up to 4 video inputs (3CH AHD + 1CH IPC) |
|
|
Video Coding |
H.265 / H.264 compatible |
|
| Road-facing camera |
|
1080P, 3.2mm lens (Horizontal angle 104°), no infrared, no audio. Integrated with the host body. |
|
Operating Voltage |
9V-36VDC |
|
|
Weight |
250g |
|
|
Power Consumption |
7W |
|
|
Operating Temperature |
-25℃~ + 75℃ |
|
MVR-DSC-Ai2-cam
|
Model |
MVR-DSC-Ai2-cam |
|
Camera type |
Analog AHD |
|
TV System |
PAL / NTSC |
|
Horizontal Resolution |
720P |
|
Lens and Horizontal angle of view |
2.1mm lens, 130° |
|
Effective Pixel |
720P:1280(H) x 720(V) |
|
Min illumination |
0.01Lux @ (F1.2, AGC ON) |
|
S/N Ratio |
More Than 60dB (AGC OFF) |
|
WDR |
D-WDR |
|
IR & Infrared LED Range |
4pcs IR LED, IR range 3 meters |
|
Audio Function |
N/A |
|
Tilt Adjusting |
Adjustable |
|
Power Supply |
12V DC ±10% |
|
Dimensions |
85*37*33.5 |
|
Net Weight |
50 g |
|
Weatherproof/Waterproof |
N/A |
|
Operating Temperature |
-25℃ ~ 75℃ |
