Description
Intelligence Features(AI)
Please click the following button for the videos of each AI features
The new iPac NX series features up to 5 Mega Pixels of stunning Ultra HD resolution combined with the Next Generation of compression standards High Efficiency Video Coding (HEVC/H.265)- which allows for bitrates nearly half those of other cameras utilizing older H.264 compression technology.The iPac NX series offers double the storage and half of the bandwidth requirements without sacrificing resolution or frame rate.
| Mechanical Specifications | |
|---|---|
| Image Sensor | 1/3"Progressive Scan CMOS |
| Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0.028 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Speed | 1/5 s- 1/20,000 s |
| Lens Type | 2.8 mm |
| Lens Mount | M12 |
| Day and Night | IR Cut Filter with Auto Switch |
| Dynamic Range | Wide Dynamic Range |
| Digital Noise Reduction | 2D / 3D DNR |
| Compression | |
| Video Compression | H.265/H.264/MJPEG |
| Image Resolution | Up to 5MP (2560 X 1960) |
| Video Bit Rate | 265K-8M |
| Image | |
| Frame Rate |
5MP (2592 X 1944) @ 15fps 960H(1280 x 960) @ 15fps |
| Image Settings | Rotate Mode, Saturation, Brightness, Contrast, Sharpness, and adjustable browser |
| Day and Night Swith | Auto/ Schedule/ Triggered by Alarm In |
| Interface | |
| System Compatibility | ONVIF 2.4, RSSP |
| Interface | 1 RJ45 10M / 100M Ethernet Interface |
| IR Distance | Flux IR Up to 75 ft |
| POE | Built-In POE |
| Security | Flash-Prevention, Dual Stream, Heartbeat, Mirror, Password Protection, Privacy Mask, IP Address Filtering |
| Electrical | |
| Power Supply | 12 VDC ± 10%, POE (802.3af) |
| Power Consumption | Max. 5 W (Max.7Wwith IR cut filter on) |
| Operating Temperature | -40 °F- 140 °F Humidity 95% or less (non-condensing) |
| Físico | |
| Dimensions | 5.7 "x 2.7" x 2.8 " |
| Net Weight | .78 lbs. |
| Clasificación climática | IP67 Rated |
| JUNCTION BOX | WALL MOUNT BRACKET | ACCESSORIES |
|
|
|
|
| Junction Box with Built-in PoE Switch | ||
|
|
